Right Angle Post Clamps

#53-357

#53-357 #88-560, Right Angle Post Mount Assembly #58-994
×
  • Basic Building Block for Optical Systems
  • Fixed Options for Mounting 12.7mm to 12.7mm or 12.7mm to 12.0mm Posts Available
  • Rotatable Option for 12.7mm to 12.7mm Posts
  • Aluminum Mount Construction

TECHSPEC® Right Angle Post Clamps are basic building blocks for optical systems. This post clamp is used to mount two of our 0.5" stainless steel posts at 90° from each other. The posts are locked in place with two ¼-20 thumbscrews. The heavy-duty design provides a stable, secure fit for tightly spaced systems. TECHSPEC Right Angle Post Clamps are constructed of anodized aluminum. Fixed clamp, fixed clamp kit, or rotatable clamp options are available.

Products

 Function   Post Clamp Size (mm)   Compare   Stock Number   Price  Buy
Fixed 12.7 - 12.7
Fixed 12.7 - 12.0
Rotatable 12.7 - 12.7
Assembly 12.7 - 12.7
