X-Y Positioning Tables
- Available Options of 70mm (±35mm)and 200mm(±100mm)Travel in Both X and Y
- Ball Bearing or Rack and Pinion Movements for Fast Adjustment
- Solid Top Designs
45° Mounting Adapters
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
- Fixed 45 Degree Mounting
- 3 Options for Different Offsets
- Aluminum Mount
Rotary Optic Mount
- Manual 360° Rotation
- Available with Pre-Mounted Linear Polarizer
- Compatible with T-Mount Optic Mounts
Top Adjustment Kinematic Mounts
- Micrometer or Lead Screw Driven Tip-Tilt Adjustment
- Color Coded Knobs for Tip and Tilt
- Set Screws and Delrin® Pads Hold Optical Component in Place
- Posts and Post Holders Required for Mounting
Imaging System Bases
- Variety of Bases Available
- Stand-Alone or Benchtop Compatible Bases
- Designed for Use with 0.75" Stainless Steel Posts
- Rack and Pinion Focusing Mounts, and Accessories also Available
M23.2 Adjustable Length Tubes
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
- Enable Adjustment of Cage System Length
- Locking Ring for Easy Length Adjustment
- M23.2 x 0.75 Threading
- Combine with Thread Adapters to Join Multiple Fixed Extension Tubes
Piezo Positioning Stages
Clearance
- High Precision Piezo Stages
- Stick-Slip Designs
- Ultra-Fine Control
Metric Polarizer Mounts
- Coarse and Fine Movement Available
- Black Anodized Aluminum
- Posts and Post Holders Required for Mounting
Tube System Spheres
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
- Ideal for Intersecting Multiple Optical Paths
- Feature M23.2 or M27.5 Threading for Integration with Cage System Tubes
- End Caps Block Unused Optical Paths
Optical Cell Assemblies
- Robust Mounts for Larger Diameter Optics
- ¼-20 Mounted Hole for Post Mounting
- Thread into Optical Cell Kinematic Mounts to Add Tip/Tilt Adjustment
Metric Ball Bearing Translation Stages
- Preloaded Ball Bearing Design for Low-Friction Linear Adjustment
- Solid-Top and Thru-Hole Versions
- English or Metric Micrometer Drive and Fine Screw Drive Available
- Stackable for 2-Axis or 3-Axis Movement
Heavy Load Capacity Rotary Positioning Stages
- Normal Load Capacity of 25lb (11.3kg) for heavy duty applications
- Precision Worm Gear Drive
- Compatible with Metric and English 5" Ball Stages
English Ball Bearing Translation Stages
- Preloaded Ball Bearing Design for Low-Friction Linear Adjustment
- Solid-Top and Thru-Hole Versions
- English or Metric Micrometer Drive and Fine Screw Drive Available
- Stackable for 2-Axis or 3-Axis Movement
Linear-Rotary Positioning Stage
Clearance
- Compact Stage with Both Linear and Rotary Positioning
- Linear Adjustment with a Fine Resolution Micrometer
- Coarse or Fine Rotary Adjustment
Positioning Stages with Digital Micrometers
- 0.001mm Resolution Directly Readable Micrometer
- Readout in Inches or Millimeters
- Available with English or Metric Mounting Holes
Linear Motion Ball Bearing Slides
- High Straight Line Accuracy
- Low Wear, Low Friction Sliding Motion
- Preloaded to Eliminate Wobble and Unwanted Play
