Infrared (IR) Wire Grid Polarizers

×
  • Designed for Wavelengths Ranging from 2 - 30μm
  • Various Substrates Available
  • 360° Rotation Using Metric Polarizer Mounts

Infrared (IR) Wire Grid Polarizers are used to polarize light from unpolarized infrared laser sources, as well as attenuate light from polarized ones. When two wire grid polarizers are used together, high extinction ratios greater than 40,000:1 can be achieved. The polarization axis of each polarizer is marked by two white lines etched into the surface of its protective ring. Infrared (IR) Wire Grid Polarizers are used in a variety of medical imaging, aerospace, FTIR spectrophotometry, and analytical instrumentation applications.

Common Specifications

Note:
Notches on polarizer ring are aligned with wires of wire grid (max. reflection)
Thickness (mm):
2.00
Parallelism (arcmin):
≤3
Dimensional Tolerance (mm):
±0.2
Construction:
Wire Grid
Groove Parallelism to Edge (°):
N/A
Angle of Incidence (°):
0
Polarization:
Notches on polarizer ring are aligned with wires of wire grid
Damage Threshold, By Design:
50 W/cm2
Groove Density (grooves/mm):
2700.00
Ring Thickness (mm):
±0.1
Mount:
Black Anodized Aluminum
Operating Temperature (°C):
-20 to 75

Products

 Mount   Operating Temperature (°C)   Substrate   Thickness (mm)  CA (mm) Dia. (mm)  Compare   Stock Number   Price  Buy
Black Anodized Aluminum -20 to 75 Barium Fluoride (BaF2) 2.00 18.0 25.00 #62-770 €1.625,00 Qty 6+ €1.300,00   Request Quote
  • In Stock
    ×

Black Anodized Aluminum -20 to 75 Barium Fluoride (BaF2) 2.00 34.0 50.00 #62-771 €2.050,00 Qty 6+ €1.640,00   Request Quote
  • 3-4 days
    ×

Black Anodized Aluminum -20 to 75 Zinc Selenide (ZnSe) 2.00 18.0 25.00 #62-772 €1.595,00 Qty 6+ €1.276,00   Request Quote
  • In Stock
    ×

Black Anodized Aluminum -20 to 75 Zinc Selenide (ZnSe) 2.00 34.0 50.00 #62-773 €2.175,00 Qty 6+ €1.740,00   Request Quote
  • 3-4 days
    ×

Black Anodized Aluminum -20 to 75 Thallium Bromoiodide (KRS-5) 2.00 18.0 25.00 #62-774 €1.925,00 Qty 6+ €1.540,00   Request Quote
  • 3-4 days
    ×

Black Anodized Aluminum -20 to 75 Thallium Bromoiodide (KRS-5) 2.00 34.0 50.00 #62-775 €2.550,00 Qty 6+ €2.040,00   Request Quote
  • 3-4 days
    ×

Black Anodized Aluminum -20 to 75 Germanium (Ge) 2.00 18.0 25.00 #62-776 €1.835,00   Request Quote
  • Contact Us
    ×


Product Details

Infrared (IR) Wire Grid Polarizers are manufactured by a special holographic technique that creates sub-micron wire grid spacing. Compared to conventional ruled wire grid methods, the holographic method creates finer groove spacing which optimizes short wavelength performance. We offer holographic wire grid polarizers of Barium Fluoride (BaF2), Zinc Selenide (ZnSe), Thallium Bromoiodide (KRS-5), and Germanium (Ge).

Note: Special care should be taken when handling KRS-5 and Zinc Selenide as they are toxic materials. Always wear rubber or plastic gloves to avoid risk of contamination. The active wire-grid surface of the polarizer is extremely delicate and nothing should be allowed to touch it, as this can damage the optic. Only dry air is recommended as a cleaning method. If necessary, this optic should be handled by the edges only and with protected fingers.
