Top Seller

High Performance OD 4.0 Longpass Filters

Cut-On Slope <1%
Rejection OD ≥ 4.0
≥91% Transmission in Pass Band
Variety of OD 4.0 Longpass Filter Kits Available

TECHSPEC® High Performance OD 4.0 Longpass Filters feature high transmission in the pass band combined with superior blocking in the rejection band. Due to a rejection band optical density of 4.0 combined with >91% in the pass band, these filters are ideal for a wide variety of applications. TECHSPEC® High Performance OD 4.0 Longpass Filters are hard coated, with a hard dielectric sputtered as the first surface and AR coating as the second. Eliminate stray light by creating custom bandpass filters when combined with TECHSPEC® High Performance Shortpass Filters.

Note: These filters are optimized for high spectral performance rather than high Laser Induced Damage Thresholds (LIDT). A typical LIDT for these filters is 1 J/cm² @ 532nm, 10ns. Please contact us if you require a filter with a higher LIDT value.

Common Specifications

Thickness Tolerance (mm):

±0.1

Physical Durability:

Adhesion per MIL-PRF-13830B, Section C.4.5.12
Moderate abrasion per MIL-PRF-13830B, Section C.4.5.11
Cleaning per MIL-C-48497A Section 4.5.4.2

Angle of Incidence (°):

Optical Density OD (Average):

≥4.0

Substrate:

Fused Silica (Corning 7980)

Coating:

Hard Coated

Surface Quality:

60-40

Transmitted Wavefront, RMS:

≤λ/4 @ 633nm (prior to coating)

Cut-On Tolerance (%):

±1

Coating Specification:

Surface 1: Hard Dielectric Sputtered
Surface 2: AR Coated

Environmental Durability:

Humidity per MIL-STD-810H, Section 507.6
Temperature per MIL-STD-810H, Section 501.7 and 502.7

Products
Product Details
Technical Information
Accessories
Related Products
Resources

Products

Dia. (mm)	Cut-On Wavelength (nm)	Thickness (mm)	Rejection Wavelength (nm)	Transmission Wavelength (nm)	Wavelength Range (nm)	Stock Number	Price	Buy
12.50 25.00 50.00	325.00 350.00 375.00 400.00 425.00 450.00 475.00 500.00 525.00 550.00 575.00 600.00 625.00 650.00 675.00 700.00 725.00 750.00 775.00 800.00 825.00 850.00 875.00 900.00 925.00 950.00 975.00 1,000.00 1,025.00 1,050.00 1,075.00 1,100.00 1,150.00 1,200.00 1,250.00 1,300.00	1.50 2.00 3.00 5.00	200 - 1005 200 - 1030 200 - 1055 200 - 1080 200 - 1130 200 - 1180 200 - 1230 200 - 1280 200 - 315 200 - 340 200 - 365 200 - 390 200 - 415 200 - 440 200 - 465 200 - 490 200 - 515 200 - 539 200 - 564 200 - 588 200 - 613 200 - 637 200 - 662 200 - 686 200 - 705 200 - 735 200 - 760 200 - 785 200 - 805 200 - 835 200 - 860 200 - 880 200 - 905 200 - 930 200 - 955 200 - 980	1020 - 1650 1045 - 1650 1070 - 1650 1095 - 1650 1120 - 1650 1170 - 1650 1220 - 1650 1270 - 1650 1320 - 1650 333 - 1600 358 - 1600 383 - 1600 408 - 1650 433 - 1650 458 - 1650 483 - 1650 508 - 1650 534 - 1650 560 - 1650 585 - 1650 610 - 1650 635 - 1650 660 - 1650 685 - 1650 710 - 1650 735 - 1650 765 - 1650 790 - 1650 815 - 1650 840 - 1650 865 - 1650 890 - 1650 915 - 1650 940 - 1650 965 - 1650 990 - 1650	200 - 1600 200 - 1650		188,00 198,00 208,00 255,00 265,00 275,00 541,00 551,00 561,00
12.50 12.50	325.00 325.00	1.50 1.50	200 - 315 200 - 315	333 - 1600 333 - 1600	200 - 1600 200 - 1600	#34-295	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	325.00 325.00	1.50 1.50	200 - 315 200 - 315	333 - 1600 333 - 1600	200 - 1600 200 - 1600	#34-296	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	325.00 325.00	1.50 1.50	200 - 315 200 - 315	333 - 1600 333 - 1600	200 - 1600 200 - 1600	#34-297	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	350.00 350.00	1.50 1.50	200 - 340 200 - 340	358 - 1600 358 - 1600	200 - 1600 200 - 1600	#34-298	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	350.00 350.00	1.50 1.50	200 - 340 200 - 340	358 - 1600 358 - 1600	200 - 1600 200 - 1600	#34-299	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	350.00 350.00	1.50 1.50	200 - 340 200 - 340	358 - 1600 358 - 1600	200 - 1600 200 - 1600	#34-300	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	375.00 375.00	1.50 1.50	200 - 365 200 - 365	383 - 1600 383 - 1600	200 - 1600 200 - 1600	#34-301	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	375.00 375.00	1.50 1.50	200 - 365 200 - 365	383 - 1600 383 - 1600	200 - 1600 200 - 1600	#34-302	265,00 €265,00 Qty 6+ €227,00 Request Quote	In Stock ×
50.00 50.00	375.00 375.00	1.50 1.50	200 - 365 200 - 365	383 - 1600 383 - 1600	200 - 1600 200 - 1600	#34-303	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	400.00 400.00	2.00 2.00	200 - 390 200 - 390	408 - 1650 408 - 1650	200 - 1650 200 - 1650	#62-974	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	400.00 400.00	3.00 3.00	200 - 390 200 - 390	408 - 1650 408 - 1650	200 - 1650 200 - 1650	#62-981	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	400.00 400.00	5.00 5.00	200 - 390 200 - 390	408 - 1650 408 - 1650	200 - 1650 200 - 1650	#84-754	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	425.00 425.00	2.00 2.00	200 - 415 200 - 415	433 - 1650 433 - 1650	200 - 1650 200 - 1650	#84-736	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	425.00 425.00	3.00 3.00	200 - 415 200 - 415	433 - 1650 433 - 1650	200 - 1650 200 - 1650	#84-742	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	425.00 425.00	5.00 5.00	200 - 415 200 - 415	433 - 1650 433 - 1650	200 - 1650 200 - 1650	#84-748	541,00 €541,00 Qty 6+ €463,00 Request Quote	In Stock ×
12.50 12.50	450.00 450.00	2.00 2.00	200 - 440 200 - 440	458 - 1650 458 - 1650	200 - 1650 200 - 1650	#62-975	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	450.00 450.00	3.00 3.00	200 - 440 200 - 440	458 - 1650 458 - 1650	200 - 1650 200 - 1650	#62-982	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	450.00 450.00	5.00 5.00	200 - 440 200 - 440	458 - 1650 458 - 1650	200 - 1650 200 - 1650	#84-755	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	475.00 475.00	2.00 2.00	200 - 465 200 - 465	483 - 1650 483 - 1650	200 - 1650 200 - 1650	#84-737	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	475.00 475.00	3.00 3.00	200 - 465 200 - 465	483 - 1650 483 - 1650	200 - 1650 200 - 1650	#84-743	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	475.00 475.00	5.00 5.00	200 - 465 200 - 465	483 - 1650 483 - 1650	200 - 1650 200 - 1650	#84-749	541,00 €541,00 Qty 6+ €463,00 Request Quote	In Stock ×
12.50 12.50	500.00 500.00	2.00 2.00	200 - 490 200 - 490	508 - 1650 508 - 1650	200 - 1650 200 - 1650	#62-976	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	500.00 500.00	3.00 3.00	200 - 490 200 - 490	508 - 1650 508 - 1650	200 - 1650 200 - 1650	#62-983	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	500.00 500.00	5.00 5.00	200 - 490 200 - 490	508 - 1650 508 - 1650	200 - 1650 200 - 1650	#84-756	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	525.00 525.00	2.00 2.00	200 - 515 200 - 515	534 - 1650 534 - 1650	200 - 1650 200 - 1650	#84-738	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	525.00 525.00	3.00 3.00	200 - 515 200 - 515	534 - 1650 534 - 1650	200 - 1650 200 - 1650	#84-744	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	525.00 525.00	5.00 5.00	200 - 515 200 - 515	534 - 1650 534 - 1650	200 - 1650 200 - 1650	#84-750	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	550.00 550.00	2.00 2.00	200 - 539 200 - 539	560 - 1650 560 - 1650	200 - 1650 200 - 1650	#62-977	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	550.00 550.00	3.00 3.00	200 - 539 200 - 539	560 - 1650 560 - 1650	200 - 1650 200 - 1650	#62-984	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	550.00 550.00	5.00 5.00	200 - 539 200 - 539	560 - 1650 560 - 1650	200 - 1650 200 - 1650	#84-757	541,00 €541,00 Qty 6+ €463,00 Request Quote	In Stock ×
12.50 12.50	575.00 575.00	2.00 2.00	200 - 564 200 - 564	585 - 1650 585 - 1650	200 - 1650 200 - 1650	#84-739	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	575.00 575.00	3.00 3.00	200 - 564 200 - 564	585 - 1650 585 - 1650	200 - 1650 200 - 1650	#84-745	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	575.00 575.00	5.00 5.00	200 - 564 200 - 564	585 - 1650 585 - 1650	200 - 1650 200 - 1650	#84-751	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	600.00 600.00	2.00 2.00	200 - 588 200 - 588	610 - 1650 610 - 1650	200 - 1650 200 - 1650	#62-978	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	600.00 600.00	3.00 3.00	200 - 588 200 - 588	610 - 1650 610 - 1650	200 - 1650 200 - 1650	#62-985	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	600.00 600.00	5.00 5.00	200 - 588 200 - 588	610 - 1650 610 - 1650	200 - 1650 200 - 1650	#84-758	541,00 €541,00 Qty 6+ €463,00 Request Quote	In Stock ×
12.50 12.50	625.00 625.00	2.00 2.00	200 - 613 200 - 613	635 - 1650 635 - 1650	200 - 1650 200 - 1650	#84-740	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	625.00 625.00	3.00 3.00	200 - 613 200 - 613	635 - 1650 635 - 1650	200 - 1650 200 - 1650	#84-746	255,00 €255,00 Qty 6+ €218,00 Request Quote	3-4 days ×
50.00 50.00	625.00 625.00	5.00 5.00	200 - 613 200 - 613	635 - 1650 635 - 1650	200 - 1650 200 - 1650	#84-752	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	650.00 650.00	2.00 2.00	200 - 637 200 - 637	660 - 1650 660 - 1650	200 - 1650 200 - 1650	#62-979	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	650.00 650.00	3.00 3.00	200 - 637 200 - 637	660 - 1650 660 - 1650	200 - 1650 200 - 1650	#62-986	255,00 €255,00 Qty 6+ €218,00 Request Quote	3-4 days ×
50.00 50.00	650.00 650.00	5.00 5.00	200 - 637 200 - 637	660 - 1650 660 - 1650	200 - 1650 200 - 1650	#84-759	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	675.00 675.00	2.00 2.00	200 - 662 200 - 662	685 - 1650 685 - 1650	200 - 1650 200 - 1650	#84-741	188,00 €188,00 Qty 6+ €160,00 Request Quote	3-4 days ×
25.00 25.00	675.00 675.00	3.00 3.00	200 - 662 200 - 662	685 - 1650 685 - 1650	200 - 1650 200 - 1650	#84-747	255,00 €255,00 Qty 6+ €218,00 Request Quote	3-4 days ×
50.00 50.00	675.00 675.00	5.00 5.00	200 - 662 200 - 662	685 - 1650 685 - 1650	200 - 1650 200 - 1650	#84-753	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	700.00 700.00	2.00 2.00	200 - 686 200 - 686	710 - 1650 710 - 1650	200 - 1650 200 - 1650	#62-980	188,00 €188,00 Qty 6+ €160,00 Request Quote	In Stock ×
25.00 25.00	700.00 700.00	3.00 3.00	200 - 686 200 - 686	710 - 1650 710 - 1650	200 - 1650 200 - 1650	#62-987	255,00 €255,00 Qty 6+ €218,00 Request Quote	In Stock ×
50.00 50.00	700.00 700.00	5.00 5.00	200 - 686 200 - 686	710 - 1650 710 - 1650	200 - 1650 200 - 1650	#84-760	541,00 €541,00 Qty 6+ €463,00 Request Quote	3-4 days ×
12.50 12.50	725.00 725.00	2.00 2.00	200 - 705 200 - 705	735 - 1650 735 - 1650	200 - 1650 200 - 1650	#86-060	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	725.00 725.00	3.00 3.00	200 - 705 200 - 705	735 - 1650 735 - 1650	200 - 1650 200 - 1650	#86-068	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	725.00 725.00	5.00 5.00	200 - 705 200 - 705	735 - 1650 735 - 1650	200 - 1650 200 - 1650	#86-076	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	750.00 750.00	2.00 2.00	200 - 735 200 - 735	765 - 1650 765 - 1650	200 - 1650 200 - 1650	#66-226	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	750.00 750.00	3.00 3.00	200 - 735 200 - 735	765 - 1650 765 - 1650	200 - 1650 200 - 1650	#66-234	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	750.00 750.00	5.00 5.00	200 - 735 200 - 735	765 - 1650 765 - 1650	200 - 1650 200 - 1650	#84-761	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	775.00 775.00	2.00 2.00	200 - 760 200 - 760	790 - 1650 790 - 1650	200 - 1650 200 - 1650	#86-061	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	775.00 775.00	3.00 3.00	200 - 760 200 - 760	790 - 1650 790 - 1650	200 - 1650 200 - 1650	#86-069	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	775.00 775.00	5.00 5.00	200 - 760 200 - 760	790 - 1650 790 - 1650	200 - 1650 200 - 1650	#86-077	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	800.00 800.00	2.00 2.00	200 - 785 200 - 785	815 - 1650 815 - 1650	200 - 1650 200 - 1650	#66-227	198,00 €198,00 Qty 6+ €169,00 Request Quote	In Stock ×
25.00 25.00	800.00 800.00	3.00 3.00	200 - 785 200 - 785	815 - 1650 815 - 1650	200 - 1650 200 - 1650	#66-235	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	800.00 800.00	5.00 5.00	200 - 785 200 - 785	815 - 1650 815 - 1650	200 - 1650 200 - 1650	#84-762	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	825.00 825.00	2.00 2.00	200 - 805 200 - 805	840 - 1650 840 - 1650	200 - 1650 200 - 1650	#86-062	198,00 €198,00 Qty 6+ €169,00 Request Quote	In Stock ×
25.00 25.00	825.00 825.00	3.00 3.00	200 - 805 200 - 805	840 - 1650 840 - 1650	200 - 1650 200 - 1650	#86-070	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	825.00 825.00	5.00 5.00	200 - 805 200 - 805	840 - 1650 840 - 1650	200 - 1650 200 - 1650	#86-078	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	850.00 850.00	2.00 2.00	200 - 835 200 - 835	865 - 1650 865 - 1650	200 - 1650 200 - 1650	#66-228	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	850.00 850.00	3.00 3.00	200 - 835 200 - 835	865 - 1650 865 - 1650	200 - 1650 200 - 1650	#66-236	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	850.00 850.00	5.00 5.00	200 - 835 200 - 835	865 - 1650 865 - 1650	200 - 1650 200 - 1650	#84-763	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	875.00 875.00	2.00 2.00	200 - 860 200 - 860	890 - 1650 890 - 1650	200 - 1650 200 - 1650	#86-063	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	875.00 875.00	3.00 3.00	200 - 860 200 - 860	890 - 1650 890 - 1650	200 - 1650 200 - 1650	#86-071	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	875.00 875.00	5.00 5.00	200 - 860 200 - 860	890 - 1650 890 - 1650	200 - 1650 200 - 1650	#86-079	551,00 €551,00 Qty 6+ €472,00 Request Quote	In Stock ×
12.50 12.50	900.00 900.00	2.00 2.00	200 - 880 200 - 880	915 - 1650 915 - 1650	200 - 1650 200 - 1650	#66-229	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	900.00 900.00	3.00 3.00	200 - 880 200 - 880	915 - 1650 915 - 1650	200 - 1650 200 - 1650	#66-237	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	900.00 900.00	5.00 5.00	200 - 880 200 - 880	915 - 1650 915 - 1650	200 - 1650 200 - 1650	#84-764	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	925.00 925.00	2.00 2.00	200 - 905 200 - 905	940 - 1650 940 - 1650	200 - 1650 200 - 1650	#86-064	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	925.00 925.00	3.00 3.00	200 - 905 200 - 905	940 - 1650 940 - 1650	200 - 1650 200 - 1650	#86-072	265,00 €265,00 Qty 6+ €227,00 Request Quote	In Stock ×
50.00 50.00	925.00 925.00	5.00 5.00	200 - 905 200 - 905	940 - 1650 940 - 1650	200 - 1650 200 - 1650	#86-080	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	950.00 950.00	2.00 2.00	200 - 930 200 - 930	965 - 1650 965 - 1650	200 - 1650 200 - 1650	#66-230	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	950.00 950.00	3.00 3.00	200 - 930 200 - 930	965 - 1650 965 - 1650	200 - 1650 200 - 1650	#66-238	265,00 €265,00 Qty 6+ €227,00 Request Quote	In Stock ×
50.00 50.00	950.00 950.00	5.00 5.00	200 - 930 200 - 930	965 - 1650 965 - 1650	200 - 1650 200 - 1650	#84-765	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	975.00 975.00	2.00 2.00	200 - 955 200 - 955	990 - 1650 990 - 1650	200 - 1650 200 - 1650	#86-065	198,00 €198,00 Qty 6+ €169,00 Request Quote	3-4 days ×
25.00 25.00	975.00 975.00	3.00 3.00	200 - 955 200 - 955	990 - 1650 990 - 1650	200 - 1650 200 - 1650	#86-073	265,00 €265,00 Qty 6+ €227,00 Request Quote	3-4 days ×
50.00 50.00	975.00 975.00	5.00 5.00	200 - 955 200 - 955	990 - 1650 990 - 1650	200 - 1650 200 - 1650	#86-081	551,00 €551,00 Qty 6+ €472,00 Request Quote	3-4 days ×
12.50 12.50	1,000.00 1,000.00	2.00 2.00	200 - 980 200 - 980	1020 - 1650 1020 - 1650	200 - 1650 200 - 1650	#66-231	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,000.00 1,000.00	3.00 3.00	200 - 980 200 - 980	1020 - 1650 1020 - 1650	200 - 1650 200 - 1650	#66-239	275,00 €275,00 Qty 6+ €237,00 Request Quote	In Stock ×
50.00 50.00	1,000.00 1,000.00	5.00 5.00	200 - 980 200 - 980	1020 - 1650 1020 - 1650	200 - 1650 200 - 1650	#84-766	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,025.00 1,025.00	2.00 2.00	200 - 1005 200 - 1005	1045 - 1650 1045 - 1650	200 - 1650 200 - 1650	#86-066	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,025.00 1,025.00	3.00 3.00	200 - 1005 200 - 1005	1045 - 1650 1045 - 1650	200 - 1650 200 - 1650	#86-074	275,00 €275,00 Qty 6+ €237,00 Request Quote	In Stock ×
50.00 50.00	1,025.00 1,025.00	5.00 5.00	200 - 1005 200 - 1005	1045 - 1650 1045 - 1650	200 - 1650 200 - 1650	#86-082	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,050.00 1,050.00	2.00 2.00	200 - 1030 200 - 1030	1070 - 1650 1070 - 1650	200 - 1650 200 - 1650	#66-232	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,050.00 1,050.00	3.00 3.00	200 - 1030 200 - 1030	1070 - 1650 1070 - 1650	200 - 1650 200 - 1650	#66-240	275,00 €275,00 Qty 6+ €237,00 Request Quote	In Stock ×
50.00 50.00	1,050.00 1,050.00	5.00 5.00	200 - 1030 200 - 1030	1070 - 1650 1070 - 1650	200 - 1650 200 - 1650	#84-767	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,075.00 1,075.00	2.00 2.00	200 - 1055 200 - 1055	1095 - 1650 1095 - 1650	200 - 1650 200 - 1650	#86-067	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,075.00 1,075.00	3.00 3.00	200 - 1055 200 - 1055	1095 - 1650 1095 - 1650	200 - 1650 200 - 1650	#86-075	275,00 €275,00 Qty 6+ €237,00 Request Quote	In Stock ×
50.00 50.00	1,075.00 1,075.00	5.00 5.00	200 - 1055 200 - 1055	1095 - 1650 1095 - 1650	200 - 1650 200 - 1650	#86-083	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,100.00 1,100.00	2.00 2.00	200 - 1080 200 - 1080	1120 - 1650 1120 - 1650	200 - 1650 200 - 1650	#66-233	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,100.00 1,100.00	3.00 3.00	200 - 1080 200 - 1080	1120 - 1650 1120 - 1650	200 - 1650 200 - 1650	#66-241	275,00 €275,00 Qty 6+ €237,00 Request Quote	3-4 days ×
50.00 50.00	1,100.00 1,100.00	5.00 5.00	200 - 1080 200 - 1080	1120 - 1650 1120 - 1650	200 - 1650 200 - 1650	#84-768	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,150.00 1,150.00	3.00 3.00	200 - 1130 200 - 1130	1170 - 1650 1170 - 1650	200 - 1650 200 - 1650	#89-657	208,00 €208,00 Qty 6+ €177,00 Request Quote	3-4 days ×
25.00 25.00	1,150.00 1,150.00	3.00 3.00	200 - 1130 200 - 1130	1170 - 1650 1170 - 1650	200 - 1650 200 - 1650	#89-661	275,00 €275,00 Qty 6+ €237,00 Request Quote	3-4 days ×
50.00 50.00	1,150.00 1,150.00	3.00 3.00	200 - 1130 200 - 1130	1170 - 1650 1170 - 1650	200 - 1650 200 - 1650	#89-665	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,200.00 1,200.00	3.00 3.00	200 - 1180 200 - 1180	1220 - 1650 1220 - 1650	200 - 1650 200 - 1650	#89-658	208,00 €208,00 Qty 6+ €177,00 Request Quote	3-4 days ×
25.00 25.00	1,200.00 1,200.00	3.00 3.00	200 - 1180 200 - 1180	1220 - 1650 1220 - 1650	200 - 1650 200 - 1650	#89-662	275,00 €275,00 Qty 6+ €237,00 Request Quote	3-4 days ×
50.00 50.00	1,200.00 1,200.00	3.00 3.00	200 - 1180 200 - 1180	1220 - 1650 1220 - 1650	200 - 1650 200 - 1650	#89-666	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×
12.50 12.50	1,250.00 1,250.00	3.00 3.00	200 - 1230 200 - 1230	1270 - 1650 1270 - 1650	200 - 1650 200 - 1650	#89-659	208,00 €208,00 Qty 6+ €177,00 Request Quote	3-4 days ×
25.00 25.00	1,250.00 1,250.00	3.00 3.00	200 - 1230 200 - 1230	1270 - 1650 1270 - 1650	200 - 1650 200 - 1650	#89-663	275,00 €275,00 Qty 6+ €237,00 Request Quote	3-4 days ×
50.00 50.00	1,250.00 1,250.00	3.00 3.00	200 - 1230 200 - 1230	1270 - 1650 1270 - 1650	200 - 1650 200 - 1650	#89-667	561,00 €561,00 Qty 6+ €482,00 Request Quote	In Stock ×
12.50 12.50	1,300.00 1,300.00	3.00 3.00	200 - 1280 200 - 1280	1320 - 1650 1320 - 1650	200 - 1650 200 - 1650	#89-660	208,00 €208,00 Qty 6+ €177,00 Request Quote	In Stock ×
25.00 25.00	1,300.00 1,300.00	3.00 3.00	200 - 1280 200 - 1280	1320 - 1650 1320 - 1650	200 - 1650 200 - 1650	#89-664	275,00 €275,00 Qty 6+ €237,00 Request Quote	3-4 days ×
50.00 50.00	1,300.00 1,300.00	3.00 3.00	200 - 1280 200 - 1280	1320 - 1650 1320 - 1650	200 - 1650 200 - 1650	#89-668	561,00 €561,00 Qty 6+ €482,00 Request Quote	3-4 days ×

Product Details

TECHSPEC® Rotating Filter Wheel can be used for applications requiring a variety of filters.
